Purpose
Recommended for woodworking, metal painting, etc.
Features
It is characterized by outstanding durability and ease of maintenance.
specification
| format | Paint/liquid supply method | Nozzle diameter [mm] | Blow air pressure [MPa] | Paint/liquid spray amount [mL/min] | (1) Pattern opening/spraying distance [mm] | Air usage [L/min] | spray gun type | nozzle shape | air cap format | Cap internal pressure [MPa] | Mass [g] | Recommended paint/liquid viscosity [sec/NK-2] | Atomization state | spray pattern | Wetted parts material | Required compressor [kW] | Connection port size Air | Connection diameter Paint | Purpose | Noise value [dB] | Operating ambient temperature [℃] | Working fluid temperature [℃] | Maximum operating air pressure [MPa] | accessories | remarks | old model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| W-77-0 | Pressure feeding type | 1.2 | 0.34 | 480 | 445/250 | 430 | General purpose | straight nozzle | -- | -- | 550 | 15～23 | General-purpose fine particles | Round to flat blowing | iron, stainless steel | 2.2～3.7 | G1/4B male | G3/8B male | -- | 82.1 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-77-02 | Pressure feeding type | 1.2 | 0.34 | 480 | 400/250 | 420 | General purpose | straight nozzle | -- | -- | 550 | 15～23 | Highly fine particles | Round to flat blowing | iron, stainless steel | 2.2～3.7 | G1/4B male | G3/8B male | -- | 82.1 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-77-1S | Suction type | 1.5 | 0.34 | 255 | 210/250 | 180 | General purpose | straight nozzle | -- | -- | 550 | 15～23 | General-purpose fine particles | Round to flat blowing | iron, stainless steel | 0.75～1.5 | G1/4B male | G3/8B male | -- | 82.1 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-77-11S | Suction type | 1.5 | 0.34 | 255 | 260/250 | 290 | General purpose | straight nozzle | -- | -- | 550 | 15～23 | Highly fine particles | Round to flat blowing | iron, stainless steel | 1.5～2.2 | G1/4B male | G3/8B male | -- | 82.1 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-77-12S | Suction type | 1.5 | 0.34 | 255 | 230/250 | 370 | General purpose | straight nozzle | -- | -- | 550 | 15～23 | Highly fine particles | Round to flat blowing | iron, stainless steel | 2.2～3.7 | G1/4B male | G3/8B male | -- | 82.1 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-77-2S | Suction type | 2.0 | 0.34 | 345 | 255/250 | 250 | General purpose | straight nozzle | -- | -- | 550 | 15～23 | General-purpose fine particles | Round to flat blowing | iron, stainless steel | 1.5～2.2 | G1/4B male | G3/8B male | -- | 82.1 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-77-21S | Suction type | 2.0 | 0.34 | 350 | 270/250 | 340 | General purpose | straight nozzle | -- | -- | 550 | 15～23 | Highly fine particles | Round to flat blowing | iron, stainless steel | 1.5～2.2 | G1/4B male | G3/8B male | -- | 82.1 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-77-3S | Suction type | 2.5 | 0.34 | 435 | 280/250 | 325 | General purpose | straight nozzle | -- | -- | 550 | 15～23 | General-purpose fine particles | Round to flat blowing | iron, stainless steel | 1.5～2.2 | G1/4B male | G3/8B male | -- | 82.1 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
