Purpose
Recommended for woodworking, metal painting, etc.
Features
It is characterized by outstanding durability and ease of maintenance.
specification
| format | Paint/liquid supply method | Nozzle diameter [mm] | Blow air pressure [MPa] | Paint/liquid spray amount [mL/min] | (1) Pattern opening/spraying distance [mm] | Air usage [L/min] | spray gun type | nozzle shape | air cap format | Cap internal pressure [MPa] | Mass [g] | Recommended paint/liquid viscosity [sec/NK-2] | Atomization state | spray pattern | Wetted parts material | Required compressor [kW] | Connection port size Air | Connection diameter Paint | Purpose | Noise value [dB] | Operating ambient temperature [℃] | Working fluid temperature [℃] | Maximum operating air pressure [MPa] | accessories | remarks | old model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| W-71-0 | Pressure feeding type | 0.8 | 0.34 | 200 | 190/200 | 240 | General purpose | straight nozzle | -- | -- | 475 | 15～23 | General-purpose fine particles | Round to flat blowing | brass, stainless steel | 1.5 | G1/4B male | G1/4B male | -- | 74.8 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-71-02 | Pressure feeding type | 1.0 | 0.34 | 300 | 265/200 | 230 | General purpose | straight nozzle | -- | -- | 475 | 15～23 | Highly fine particles | Round to flat blowing | brass, stainless steel | 1.5 | G1/4B male | G1/4B male | -- | 74.8 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-71-1S | Suction type | 1.0 | 0.29 | 95 | 100/200 | 75 | General purpose | straight nozzle | -- | -- | 475 | 15～23 | General-purpose fine particles | Round to flat blowing | brass, stainless steel | 0.4 | G1/4B male | G1/4B male | -- | 74.8 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-71-2S | Suction type | 1.3 | 0.29 | 135 | 135/200 | 85 | General purpose | straight nozzle | -- | -- | 475 | 15～23 | Highly fine particles | Round to flat blowing | brass, stainless steel | 0.4 | G1/4B male | G1/4B male | -- | 74.8 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-71-3S | Suction type | 1.5 | 0.29 | 180 | 170/200 | 165 | General purpose | straight nozzle | -- | -- | 475 | 15～23 | General-purpose fine particles | Round to flat blowing | brass, stainless steel | 0.75 | G1/4B male | G1/4B male | -- | 74.8 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-71-21S | Suction type | 1.3 | 0.29 | 140 | 155/200 | 195 | General purpose | straight nozzle | -- | -- | 475 | 15～23 | Highly fine particles | Round to flat blowing | brass, stainless steel | 1.5 | G1/4B male | G1/4B male | -- | 74.8 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-71-31S | Suction type | 1.5 | 0.29 | 170 | 170/200 | 230 | General purpose | straight nozzle | -- | -- | 475 | 15～23 | Highly fine particles | Round to flat blowing | brass, stainless steel | 1.5 | G1/4B male | G1/4B male | -- | 74.8 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-71-4S | Suction type | 1.8 | 0.29 | 195 | 200/200 | 230 | General purpose | straight nozzle | -- | -- | 475 | 15～23 | General-purpose fine particles | Round to flat blowing | brass, stainless steel | 1.5 | G1/4B male | G1/4B male | -- | 74.8 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-71-1G | gravity type | 1.0 | 0.29 | 110 | 120/200 | 75 | General purpose | straight nozzle | -- | -- | 475 | 15～23 | General-purpose fine particles | Round to flat blowing | brass, stainless steel | 0.4 | G1/4B male | G1/4B male | -- | 74.8 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-71-2G | gravity type | 1.3 | 0.29 | 155 | 155/200 | 85 | General purpose | straight nozzle | -- | -- | 475 | 15～23 | Highly fine particles | Round to flat blowing | brass, stainless steel | 0.4 | G1/4B male | G1/4B male | -- | 74.8 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-71-3G | gravity type | 1.5 | 0.29 | 210 | 185/200 | 165 | General purpose | straight nozzle | -- | -- | 475 | 15～23 | General-purpose fine particles | Round to flat blowing | brass, stainless steel | 0.4 | G1/4B male | G1/4B male | -- | 74.8 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-71-21G | gravity type | 1.3 | 0.29 | 160 | 165/200 | 195 | General purpose | straight nozzle | -- | -- | 475 | 15～23 | Highly fine particles | Round to flat blowing | brass, stainless steel | 1.5 | G1/4B male | G1/4B male | -- | 74.8 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-71-31G | gravity type | 1.5 | 0.29 | 190 | 185/200 | 230 | General purpose | straight nozzle | -- | -- | 475 | 15～23 | General-purpose fine particles | Round to flat blowing | brass, stainless steel | 1.5 | G1/4B male | G1/4B male | -- | 74.8 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
| W-71-4G | gravity type | 1.8 | 0.29 | 220 | 230/200 | 230 | General purpose | straight nozzle | -- | -- | 475 | 15～23 | Highly fine particles | Round to flat blowing | brass, stainless steel | 1.5 | G1/4B male | G1/4B male | -- | 74.8 | 5～40 | 5～40 | 0.68 | brush | -- | -- |
