Purpose
Recommended for plastic models, painting textiles, arts and crafts, do-it-yourself work, car repair, and minor scratches.
Features
Three types of nozzle diameters are available (Φ0.4, 0.6, and 1.0mm). Since the air volume is small at max. 50L/min, it can also be used with a compressor of around 0.2kW.
specification
| format | Paint/liquid supply method | Nozzle diameter [mm] | Blow air pressure [MPa] | Paint/liquid spray amount [mL/min] | (1) Pattern opening/spraying distance [mm] | Air usage [L/min] | spray gun type | nozzle shape | air cap format | Cap internal pressure [MPa] | Mass [g] | Recommended paint/liquid viscosity [sec/NK-2] | Atomization state | spray pattern | Wetted parts material | Required compressor [kW] | Connection port size Air | Connection diameter Paint | Purpose | Noise value [dB] | Operating ambient temperature [℃] | Working fluid temperature [℃] | Maximum operating air pressure [MPa] | accessories | remarks | old model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| RG-3L-1 | gravity type | 0.4 | 0.24 | 15 | 25/200 | 30 | General purpose | straight nozzle | -- | -- | 180 | 12 | Highly fine particles | Marubuki | brass, aluminum, stainless steel | 0.2～0.75 | G1/4B male | G1/4B male | Plastic models, drawing textiles, arts and crafts, do-it-yourself work, car repair, tiny scratches | 62 | 5～40 | 5～43 | 0.68 | brush | -- | RG-2-1 |
| RG-3L1-1 | gravity type | 0.4 | 0.24 | 15 | 25/200 | 30 | General purpose | straight nozzle | -- | -- | 180 | 12 | Highly fine particles | Marubuki | brass, aluminum, stainless steel | 0.2～0.75 | G1/4B male | G1/4B male | Plastic models, drawing textiles, arts and crafts, do-it-yourself work, car repair, tiny scratches | 62 | 5～40 | 5～43 | 0.68 | brush | With air volume adjustment device | RG-2-1 |
| RG-3L-2 | gravity type | 0.6 | 0.24 | 35 | 35/200 | 30 | General purpose | straight nozzle | -- | -- | 180 | 12 | Highly fine particles | Marubuki | brass, aluminum, stainless steel | 0.2～0.75 | G1/4B male | G1/4B male | Plastic models, drawing textiles, arts and crafts, do-it-yourself work, car repair, tiny scratches | 62 | 5～40 | 5-43 | 0.68 | brush | -- | RG-2-2 |
| RG-3L1-2 | gravity type | 0.6 | 0.24 | 35 | 35/200 | 30 | General purpose | straight nozzle | -- | -- | 180 | 12 | Highly fine particles | Marubuki | brass, aluminum, stainless steel | 0.2～0.75 | G1/4B male | G1/4B male | Plastic models, drawing textiles, arts and crafts, do-it-yourself work, car repair, tiny scratches | 62 | 5～40 | 5-43 | 0.68 | brush | With air volume adjustment device | RG-2-2 |
| RG-3L-3 | gravity type | 1.0 | 0.24 | 80 | 35/200 | 50 | General purpose | straight nozzle | -- | -- | 180 | 12 | Highly fine particles | Marubuki | brass, aluminum, stainless steel | 0.2～0.75 | G1/4B male | G1/4B male | Plastic models, drawing textiles, arts and crafts, do-it-yourself work, car repair, tiny scratches | 62 | 5～40 | 5～43 | 0.68 | brush | -- | RG-2-3 |
| RG-3L1-3 | gravity type | 1.0 | 0.24 | 80 | 35/200 | 50 | General purpose | straight nozzle | -- | -- | 180 | 12 | Highly fine particles | Marubuki | brass, aluminum, stainless steel | 0.2～0.75 | G1/4B male | G1/4B male | Plastic models, drawing textiles, arts and crafts, do-it-yourself work, car repair, tiny scratches | 62 | 5～40 | 5～43 | 0.68 | brush | -- | RG-2-3 |
