Features

It is non-adhesive, has good water repellency, and is highly smooth, making it easy to change materials and clean.

Note

Urethane paint hoses (PHU, THU) cannot be used with paints and thinners that have strong dissolving power and are easily reactive, such as ketone solvents, two-component reactive paints, and urethane paints, as the hose may burst and the paint may scatter, making it dangerous. yeah. In this case, please use a nylon paint hose (PHN) or a fluorine liner hose (PHF).

specification

formatMaterial (name)Inner diameter x outer diameter [Φ]length [m]Maximum working pressure [MPa]
PHF-620 Urethane inner fluorine lining paint hose 6.5×9.5 20 0.69
PHF-6100 Urethane inner fluorine lining paint hose 6.5×9.5 100 0.69
PHF-820 Urethane inner fluorine lining paint hose 8.9×12.1 20 0.69
PHF-8100 Urethane inner fluorine lining paint hose 8.9×12.1 100 0.69
