Purpose

・Automatic painting equipment
, robot painting, etc.

specification

formatWetted parts materialDischarge volume [mL/rotation]Recommended discharge volume range [mL/min]Maximum allowable rotation speed [rpm/min]Maximum working pressure [MPa]Flushable mechanismFlushable working pressure [MPa]Usable viscosityCompatible paintOperating ambient temperature [℃]Working fluid temperature [℃]Paint/fluid joint inlet sizePaint/Fluid Joint Outlet SizeOverall length x overall width x overall height [mm]Mass [kg]accessoriesremarks
GPA-F15 stainless 1.5 10～100 250 2.0 Yes 0.3～0.5 30 seconds/NK-2 or less solid metallic paint 5～40 5～43 G1/4B male G1/4B male 203×85×66.5 2.75 -- --
GPA-N15 stainless 1.5 10～100 250 2.0 Nothing ⁻ 30 seconds/NK-2 or less solid metallic paint 5～40 5～43 G1/4B male G1/4B male 130×85×66.5 2.35 -- --
