There are two models available: 1.5kW and 2.2kW.
It offers overwhelming silence and overwhelming ease of use.

There are two models available: 1.5kW and 2.2kW. It offers overwhelming silence and overwhelming ease of use.

Purpose

In addition to the low-noise SLP series, we have added a design that is even quieter.
It is suitable for research facilities and dental clinics where the noise of compressor operation itself is objectionable, as well as small factories where it is important to prevent noise problems with neighbors.

Features

・The world's quietest compressor (*1)
・Provides class zero level oil-free air.
・No need for daily oil management.
・With a built-in stainless steel tank, not only the air but also the drain is clean
*1, as an oil-free type 1.5/2.2kW class (as of August 2020, according to our research)

Specification

format[Electric motor] Output [kW]Control pressure lower limit [MPa]Control pressure upper limit [MPa]Discharge air volume 50Hz/60Hz [L/min][Electric motor] Power supply
SLP-15EFPD 1.5 0.65 0.80 170 AC200V
SLP-22EFPD 2.2 0.65 0.80 255 AC200V



・The amount of air discharged is the average value of the amount of air discharged at maximum pressure converted to the suction state (atmospheric pressure).
Please contact us for guaranteed values.
-Noise values ​​are measured in an anechoic chamber under full load, so noise values ​​may vary depending on the customer's usage environment.
　For sets with an air dryer, the noise will increase by 1dB(A) from the specification table when the dryer is operating.
Note) Specifications are subject to change without notice due to product improvement.
- Ground vibration values ​​are measured at a position 1m from the side of the compressor.
　(Vibration values ​​vary depending on ground conditions. The data are reference values ​​when left on a normal concrete floor.)
- External dimensions are the outer circumferential dimensions of the package. Does not include protrusions such as ball valves.
