Purpose

■By improving the suction power of high-performance and highly functional
paints, it is possible to stably discharge a wide range of paints from low-viscosity paints to high-viscosity paints.
■Improved operability
The suction hose is soft and the installation direction is vertical, making it easy to operate regardless of where you place the paint can.
■Improved durability
The discharge valve is made of fine ceramics.
■Easy maintenance
The discharge valve has an easy-to-separate structure using a cap nut, so anyone can easily remove clogging with paint scum and release stuck balls.

Selection list by paint (application)

・Lacquer (metal/woodworking): ○
・Melamine (general metal): ○
・Chassis paint (vehicle): ◎
・Phthalic acid (vehicle): ◎
・Water-based paint (architecture): ◎
・Synthetic resin blend paint (architecture) :◎
・Acrylic (general metal):〇
・Vinyl paint (architecture/metal):◎
・Red lead (steel frame):〇
・General rust prevention paint (steel frame):◎
・Synthetic resin varnish (woodworking):✕
・Epoxy resin (General metals): 〇
・Urethane (woodworking):✕
・Ship bottom paint (shipbuilding):✕
・Chlorinated rubber-based (shipbuilding):✕
・Tar epoxy (shipbuilding/metal):✕
・Single layer elastic paint (architecture):✕

Features of diaphragm pump

Airless painting is a painting method in which high pressure is applied directly to the paint using a plunger pump or diaphragm pump, and the paint is sprayed through a small single hole (nozzle tip) to atomize it.
Although it is inferior to air spray guns in terms of atomization, it is superior in thick coating and coating efficiency.
・Improves the working environment.Compared
　to air spray, there is less paint scattering, so you can work more hygienically.
・You can save time when working
　with paint.One coat can provide 2 to 3 times as much paint film as air spray, so work time can be significantly shortened.
・
　We have a lineup of over 80 types of nozzle tips, and you can choose from a variety of paint ejection amounts and pattern widths.

specification
