Features
For continuous painting work where the paint color is almost constant, a pressurized paint tank containing 10L to 80L is convenient.
There are manual and automatic types equipped with an agitation device to prevent paint from settling.
The automatic type uses an air motor to continuously stir, so it is convenient for paints that tend to settle or when the painting site is far away.
The inner container (optional) is installed inside the paint pressurized tank and is ideal for cases where color changes are often performed. (Material: SUS304)
specification
| format | old model | type | Tank capacity [L] | Common capacity upper limit [L] | Common capacity lower limit [L] | Maximum working pressure [MPa] | Mass [kg] | Body material | Lid packing material | Operating temperature range [℃] | Air supply port | Air outlet | Paint/fluid outlet | Paint/fluid inlet filter | Food liquid outlet | Food liquid suction port filter | Container inner finish | Overall length x overall width x overall height [mm] | Level gauge | Air pressure reducing valve type | air motor type | Inner container format (actual capacity) | accessories | remarks |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PT-10D | -- | General purpose | Ten | 8.4 | 2.6 | 0.34 | 13 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×1 piece | 60 mesh | -- | -- | shot blasting treatment | 315×315×547 | -- | RR-56B | none | PTC-10W(6L) | -- | Inner container is sold separately. |
| PT-20D | -- | General purpose | 20 | 18.8 | 4.9 | 0.34 | 20 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×1 piece | 60 mesh | -- | -- | shot blasting treatment | 310×390×652 | -- | RR-56B | none | PTC-20W(14L) | -- | Inner container is sold separately. |
| PT-40D | -- | General purpose | 40 | 35.6 | 10.7 | 0.18 | 27 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×2 pieces | 60 mesh | -- | -- | shot blasting treatment | 460×465×700 | -- | RR-56B | none | PTC-40W(28L) | -- | Inner container is sold separately. |
| PT-60D | -- | General purpose | 60 | 52.6 | 10.7 | 0.18 | 35 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×2 pieces | 60 mesh | -- | -- | shot blasting treatment | 500×465×885 | -- | RR-56B | none | PTC₋60W(46L) | -- | Inner container is sold separately. |
| PT-80D | -- | General purpose | 80 | 68.8 | 10.9 | 0.18 | 39 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×2 pieces | 60 mesh | -- | -- | shot blasting treatment | 500×465×1045 | -- | RR-56B | none | PTC₋80W(62L) | -- | Inner container is sold separately. |
| PT-10DM | -- | General purpose | Ten | 8.4 | 2.6 | 0.34 | 14 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×1 piece | 60 mesh | -- | -- | shot blasting treatment | 315×315×470 | -- | RR-56B | AM-5C | PTC₋10W(6L) | -- | Inner container is sold separately. |
| PT-20DM | -- | General purpose | 20 | 18.8 | 4.9 | 0.34 | twenty three | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×1 piece | 60 mesh | -- | -- | shot blasting treatment | 310×390×590 | -- | RR-56B | AM-3C | PTC₋20W (14L) | -- | Inner container is sold separately. |
| PT-40DM | -- | General purpose | 40 | 35.6 | 10.7 | 0.18 | 31 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×2 pieces | 60 mesh | -- | -- | shot blasting treatment | 460×465×648 | -- | RR-56B | AM-3C | PTC-40W(28L) | -- | Inner container is sold separately. |
| PT-60DM | -- | General purpose | 60 | 52.6 | 10.7 | 0.18 | 38 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×2 pieces | 60 mesh | -- | -- | shot blasting treatment | 500×465×828 | -- | RR-56B | AM-3C | PTC₋60W(46L) | -- | Inner container is sold separately. |
| PT-80DM | -- | General purpose | 80 | 68.8 | 10.9 | 0.18 | 42 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×2 pieces | 60 mesh | -- | -- | shot blasting treatment | 500×465×1000 | -- | RR-56B | AM-3C | PTC₋80W(62L) | -- | Inner container is sold separately. |
| PT-10DW | -- | For water-based paints | Ten | 8.4 | 2.6 | 0.34 | 13 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×1 piece | 60 mesh | -- | -- | Powder coating | 315×315×547 | -- | RR-56B | none | PTC₋10W(6L) | -- | Inner container is sold separately. |
| PT-20DW | -- | For water-based paints | 20 | 18.8 | 4.9 | 0.34 | 20 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×1 piece | 60 mesh | -- | -- | Powder coating | 310×380×652 | -- | RR-56B | none | PTC₋20W (14L) | -- | Inner container is sold separately. |
| PT-10DMW | -- | For water-based paints | Ten | 8.4 | 2.6 | 0.34 | 14 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×1 piece | 60 mesh | -- | -- | Powder coating | 315×315×470 | -- | RR-56B | AM₋5C | PTC₋10W(6L) | -- | Inner container is sold separately. |
| PT-20DMW | -- | For water-based paints | 20 | 18.8 | 4.9 | 0.34 | twenty three | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×1 piece | 60 mesh | -- | -- | Powder coating | 310×390×590 | -- | RR-56B | AM-3C | PTC₋20W (14L) | -- | Inner container is sold separately. |
| PT-40DMW | -- | For water-based paints | 40 | 35.6 | 10.7 | 0.18 | 31 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×2 pieces | 60 mesh | -- | -- | Powder coating | 460×465×648 | -- | RR-56B | AM₋3C | PTC₋40W(28L) | -- | Inner container is sold separately. |
| PT-60DMW | -- | For water-based paints | 60 | 52.6 | 10.7 | 0.18 | 38 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×2 pieces | -- | -- | -- | Powder coating | 500×465×828 | -- | RR-56B | AM₋3C | PTC₋60W(46L) | -- | Inner container is sold separately. |
| PT-80DMW | -- | For water-based paints | 80 | 68.8 | 10.9 | 0.18 | 42 | iron | foamed polyethylene | 5~40 | G1/4B male | G1/4B male | G3/8B×2 pieces | 60 mesh | -- | -- | Powder coating | 500×465×1000 | -- | RR-56B | AM-3C | PTC₋80W(62L) | -- | Inner container is sold separately. |
