Due to the highly efficient counter electrode arrangement, -60KV output provides performance equivalent to -70KV.
Due to the highly efficient counter electrode arrangement, -60KV output provides performance equivalent to -70KV. Additionally, the counter electrode is air purged during spraying to prevent contamination.
The intermediate sheet method allows the paint nozzle and pin electrode to be replaced while the paint is still pressurized.
Since the paint valve is a cartridge type, maintenance has been greatly improved.
A connector system is used to connect the low voltage cable to the gun body, making it easy to replace the low voltage cable.
Since the atomization air and pattern air are separated into separate circuits, the pattern width can be adjusted remotely.
specification
| format | old model | Paint/liquid supply method | Nozzle diameter [mm] | Blow air pressure Atomizing air [MPa] | Blow air pressure Pattern air [MPa] | Paint/liquid spray amount [mL/min] | Pattern opening/spraying distance [mm] | Air usage [L/min] | air cap format | Cap internal pressure [MPa] | High voltage generation method | Output voltage [kV] | Output voltage [V] | Input voltage [V] | Output current [A] | Power consumption [W] | Charge ON/OFF mechanism | Mass [g] | Recommended paint viscosity [sec/NK-2] | Atomization state | spray pattern | Body material | Wetted parts material | Required compressor [kW] | Connection port size Air | Connection port size Operating air | Connection diameter Paint | Purpose | Noise value [dB] | Working fluid temperature [℃] | Operating ambient temperature [℃] | Ambient humidity [%RH] | Maximum working pressure [MPa] | Overall length x overall width x overall height [mm] | Accessories Low voltage cable [m] | Accessories Paint hose [m] | Accessories Air hose [m] | Accessories Others | Applicable controller | remarks |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| EBG-210B | -- | Pressure feeding type | 1.5 | 0.27 | -- | 300 | 370/300 | 560 | -- | -- | -- | DC-60 | -- | AC12 | -- | -- | -- | 2100 | 20 | Medium to high general purpose atomization | -- | polyacetal | polyacetal | 7.5 | -- | -- | -- | -- | -- | 5～43 | 5～40 | 70 | Air: 0.68 Paint: 0.35 | 253×80×80 | Ten | Sold separately | Sold separately | -- | E-SC12BH | Paint hose and air hose sold separately |
| EBGL-210B | -- | Pressure feeding type | 1.8 | 0.17 | 0.10 | 300 | 300/250 | 520 | -- | -- | -- | DC-60 | -- | AC12 | -- | -- | -- | 2100 | 20 | low pressure atomization | -- | polyacetal | polyacetal | 7.5 | -- | -- | -- | -- | -- | 5～43 | 5～40 | 70 | Air: 0.68 Paint: 0.35 | 253×80×80 | Ten | Sold separately | Sold separately | -- | E-SC12BH | Paint hose and air hose sold separately |
