Purpose

・Metal painting for factory lines

specification

formatTotal length [mm]Weight [g]Body external head part [Φ]Motor bearing methodRegular rotation speedHigh voltage application method [kV]High voltage value [kV]storage paint valveAir consumption Bearing air [NL/min]Air consumption Turbine air [NL/min]Air consumption Shaping air [NL/min]Paint discharge amount
E-AR100 465 3900 Φ64 Air bearing type air turbine motor 20,000～80,000r.pm (at 300mL/min) Direct application/internal boost method Regular use -40~-60kV 1 trigger valve 50NL/min (at 0.5MPa) ～250NL/min ～500NL/min Charged metallic (spiral tube) 30-180mL/min
E-AR100-NE 230 2000 Φ64 Air bearing type air turbine motor 20,000～80,000r.pm (at 300mL/min) - - 1 trigger valve 50NL/min (at 0.5MPa) ～250NL/min ～500NL/min Uncharged 30~300mL/min
