What is a glaze (abrasive functional liquid) spray gun?
A spray gun dedicated to spraying glaze on sanitary ware (toilets, wash basins, etc.), tableware, enamel products, etc. In addition to glazes, it can also be used to spray abrasives, highly abrasive functional agents, and Teflon.
specification
| format | Paint/liquid supply method | Nozzle diameter [mm] | Blow air pressure Atomizing air [MPa] | Paint/liquid spray amount [mL/min] | (1) Pattern opening/spraying distance [mm] | Air usage [L/min] | spray gun type | nozzle shape | air cap format | Mass [g] | Recommended paint/liquid viscosity [sec/NK-2] | Blow air pressure Pattern air [MPa] | Atomization state | spray pattern | Wetted parts material | Body material | Required compressor [kW] | Connection port size Atomizing air | Connection size pattern air | Connection port size Operating air | Port size Paint/liquid | Purpose | Noise value [dB] | Operating ambient temperature [℃] | Working fluid temperature [℃] | Maximum operating air pressure [MPa] | accessories | remarks |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| WRA-200-201ZP | Pressure feeding type | 2.0 | 0.34 | 760 | 370/200 | 500 | General purpose | straight nozzle | ZP2-A20 | 450 | -- | -- | General-purpose fine particles | Round to flat blowing | -- | -- | -- | Φ8 tube | -- | Φ8 tube | G3/8 | -- | -- | 5～40 | 5～43 | -- | -- | -- |
