Purpose

The most common spray gun, which is slightly larger than WIDER1, can be used for a variety of industries and paints.
Automotive painting, woodworking, metal, resin, and even hobbies.

From W-200 to WIDER2 (low pressure spray gun; from LPH-200 to WIDER2L)

The most important things in industrial coating products
are "quality and stability." 22 years have passed since the release of
our best-selling small spray gun W-200. We have poured the experience and know-how we have cultivated around the world into this new model "WIDER."

Features

・Ergonomic design with emphasis on functionality
・Simple maintenance
・Pattern adjustment device that responds linearly
・Equipped with a new air valve seat set (structure that minimizes individual differences between spray guns)

specification



formatPaint/liquid supply methodNozzle diameter [mm]Blow air pressure [MPa]Paint/liquid spray amount [mL/min](1) Pattern opening/spraying distance [mm]Air usage [L/min]spray gun typenozzle shapeair cap formatCap internal pressure [MPa]Mass [g]Recommended paint/liquid viscosity [sec/NK-2]Atomization statespray patternWetted parts materialRequired compressor [kW]Connection port size AirConnection diameter PaintPurposeNoise value [dB]Operating ambient temperature [℃]Working fluid temperature [℃]Maximum operating air pressure [MPa]accessoriesremarksold model
WIDER2-12G2P Pressure feeding type 1.2 0.29 500 400/250 500 General purpose straight nozzle WIDER2-G2P -- 375 20 Highly fine particles Round to flat blowing stainless 2.2~3.7 G1/4B male G3/8B male Automotive line painting, large buses/trucks, metal, woodwork/furniture, steel frames, adhesives 80 5～40 5-43 0.7 brush -- W-200-122P
WIDER2-15K1S Suction type 1.5 0.29 240 210/250 200 General purpose straight nozzle WIDER2-K1 -- 375 20 General-purpose fine particles Round to flat blowing stainless 0.75~1.5 G1/4B male G3/8B male Metal, woodwork/furniture, steel frame 80 5～40 5-43 0.7 brush -- W-200-151S
WIDER2-15K2S Suction type 1.5 0.29 240 290/250 330 General purpose straight nozzle WIDER2-K2 -- 375 20 Highly fine particles Round to flat blowing stainless 1.5~2.2 G1/4B male G3/8B male Large buses/trucks, metal, woodwork/furniture 80 5～40 5-43 0.7 brush -- W-200-152S
WIDER2-18K2S Suction type 1.8 0.29 290 340/250 330 General purpose straight nozzle WIDER2-K2 -- 375 20 Highly fine particles Round to flat blowing stainless 1.5~2.2 G1/4B male G3/8B male Large buses/trucks, metal, woodwork/furniture, adhesives 80 5～40 5-43 0.7 brush -- W-200-182S
WIDER2-20R1S Suction type 2.0 0.29 350 260/250 260 General purpose straight nozzle WIDER2-R1 -- 375 20 General-purpose fine particles Round to flat blowing stainless 1.5~2.2 G1/4B male G3/8B male Metal, woodwork/furniture, steel frames, adhesives 80 5～40 5-43 0.7 brush -- W-200-201S
WIDER2-20R2S Suction type 2.0 0.29 350 290/250 360 General purpose straight nozzle WIDER2-R2 -- 375 20 Highly fine particles Round to flat blowing stainless 1.5~2.2 G1/4B male G3/8B male Large bus/truck, metal 80 5～40 5-43 0.7 brush -- W-200-202S
WIDER2-25W1S Suction type 2.5 0.29 440 280/250 360 General purpose straight nozzle WIDER2-W1 -- 375 20 General-purpose fine particles Round to flat blowing stainless 1.5~2.2 G1/4B male G3/8B male Metal, woodwork/furniture, steel frames, adhesives 80 5～40 5-43 0.7 brush -- W-200-251S
WIDER2-15K1G gravity type 1.5 0.29 270 220/250 200 General purpose straight nozzle WIDER2-K1 -- 375 20 General-purpose fine particles Round to flat blowing stainless 0.75~1.5 G1/4B male G3/8B male Metal, woodwork/furniture, steel frame 80 5～40 5-43 0.7 brush -- W-200-151G
WIDER2-15K2G gravity type 1.5 0.29 270 320/250 330 General purpose straight nozzle WIDER2-K2 -- 375 20 Highly fine particles Round to flat blowing stainless 1.5~2.2 G1/4B male G3/8B male Large buses/trucks, metal, woodwork/furniture 80 5～40 5-43 0.7 brush -- W-200-152G
WIDER2-18K2G gravity type 1.8 0.29 320 380/250 330 General purpose straight nozzle WIDER2-K2 -- 375 20 Highly fine particles Round to flat blowing stainless 1.5~2.2 G1/4B male G3/8B male Large buses/trucks, metal, woodwork/furniture, adhesives 80 5～40 5-43 0.7 brush -- W-200-182G
WIDER2-20R1G gravity type 2.0 0.29 410 280/250 260 General purpose straight nozzle WIDER2-R1 -- 375 20 General-purpose fine particles Round to flat blowing stainless 1.5~2.2 G1/4B male G3/8B male Metal, woodwork/furniture, steel frames, adhesives 80 5～40 5-43 0.7 brush -- W-200-201G
WIDER2-20R2G gravity type 2.0 0.29 410 320/250 360 General purpose straight nozzle WIDER2-R2 -- 375 20 Highly fine particles Round to flat blowing stainless 1.5~2.2 G1/4B male G3/8B male Large bus/truck, metal 80 5～40 5-43 0.7 brush -- W-200-202G
WIDER2-25W1G gravity type 2.5 0.29 510 310/250 360 General purpose straight nozzle WIDER2-W1 -- 375 20 General-purpose fine particles Round to flat blowing stainless 1.5~2.2 G1/4B male G3/8B male Metal, woodwork/furniture, steel frames, adhesives 80 5～40 5-43 0.7 brush -- W-200-251G
WIDER2L-10G2P Pressure feeding type 1.0 0.20 300 250/200 470 low pressure straight nozzle WIDER2L-G2 0.069 375 20 Highly fine particles Round to flat blowing stainless 2.2~3.7 G1/4B male G3/8B male Automotive line painting, metal, woodwork/furniture 80 5～40 5-43 0.7 brush -- --
WIDER2L-12G2P Pressure feeding type 1.2 0.20 500 300/200 470 low pressure straight nozzle WIDER2L-G2 0.069 375 20 Highly fine particles Round to flat blowing stainless 2.2~3.7 G1/4B male G3/8B male Automotive line painting, large buses/trucks, metal, woodwork/furniture 80 5～40 5-43 0.7 brush -- LPH-200-122P
WIDER2L-14G2P Pressure feeding type 1.4 0.20 500 300/200 470 low pressure straight nozzle WIDER2L-G2 0.069 375 20 Highly fine particles Round to flat blowing stainless 2.2~3.7 G1/4B male G3/8B male Automotive line painting, large buses/trucks, metal, woodwork/furniture 80 5～40 5-43 0.7 brush -- --
WIDER2L-2-10G2P Pressure feeding type 1.0 0.20 130 280/200 430 low pressure split nozzle WIDER2L-2-G2 0.069 375 20 Highly fine particles Round to flat blowing stainless 2.2~3.7 G1/4B male G3/8B male Automotive line painting, metal, woodwork/furniture 80 5～40 5-43 0.7 brush -- --
WIDER2L-2-12G2P Pressure feeding type 1.2 0.20 150 300/200 430 low pressure split nozzle WIDER2L-2-G2 0.069 375 20 Highly fine particles Round to flat blowing stainless 2.2~3.7 G1/4B male G3/8B male Automotive line painting, large buses/trucks, metal, woodwork/furniture 80 5～40 5-43 0.7 brush -- --
