Features
The standard lineup has a length of 40mm.
This is a round type spray gun with a long neck tip. Unlike single-angle spray guns, there is no spray angle.
Since it can be sprayed in close proximity, scattering can be suppressed and masking efforts can be reduced.
◆Liquids used: Paints, rust preventives, functional agents, etc.
◆Viscosity range used: Within 15 seconds/NK-2 (40mPa･s).
Main unit features
・Ergonomic design with emphasis on functionality
・Simple maintenance
・Equipped with a new air valve seat set (structure that minimizes individual differences between spray guns)
specification
| format | old model | Paint/liquid supply method | spray gun type | Nozzle diameter [mm] | nozzle shape | Recommended paint/liquid viscosity [sec/NK-2] | Blow air pressure [MPa] | Blow air pressure [MPa] | Air usage [L/min] | Air usage [L/min] | (1) Pattern opening/spraying distance [mm] | air cap format | Atomization state | spray pattern | Wetted parts material | Required compressor [kW] | Mass [g] | Connection port size Air | Connection diameter Paint | Purpose | paint/liquid | solvent/aqueous | Noise value [dB] | Operating ambient temperature [℃] | Working fluid temperature [℃] | Maximum operating air pressure [MPa] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| W-101-S45S | -- | Suction type | General purpose | 1.0 | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- | 474 | -- | -- | -- | -- | -- | -- | 5～40 | 5～43 | -- |
