Features

・High discharge accuracy and easy settings
Repeatable discharge accuracy can be maintained within ±2%
Discharge amount can be adjusted digitally for easy fine adjustment

・Washing time reduction function
If you want to shorten the cleaning time by changing colors etc. A type with a cleaning shortening mechanism (flushable mechanism) that
can be applied to is available Comprehensive support including control panel

- Significant reduction in cleaning thinner
Cleaning amount is approximately 1/6 to 1/8 compared to conventional paint pumps Can

Notes

*1: 10% reduction in discharge volume and approximate lifespan of the pump body [when a standard pump is used at 120 revolutions per minute for 8 hours a day]　　
　　○General paints [melamine, acrylic, etc.] 6 months to 2 years
　　○Premix multi-liquid paint...2 months to 2 years
　　○Metallic paint...2 months to 6 months
　　○Water-based paint/paint with abrasive pigments...1 month to 6 months

*2 : Caution regarding the paint used　　 　
① If paint containing abrasive pigments is used, the life may be extremely shortened.
② Gear pumps on the hardener side used in two-liquid systems should be overhauled regularly every 1 to 2 months, as the hardener will solidify on the bearings.
③Cannot be used for paints that deteriorate or harden when shearing force is applied (emulsion paints, dispersion paints, UV paints).
　　
*3: Flushable mechanism: Improves cleaning performance by bypassing the paint inlet and outlet.

specification
