Equipped with afterpurge function as standard

After burner operation is complete, the afterpurge function works to cool down the inside of the furnace.
After cooling is complete, the circulation fan will automatically stop.

Easy to carry in and out of workpieces

The door can be opened to the full width. Workpieces can be taken in and out of the furnace along with the transport vehicle.
The furnace is equipped with shelf brackets that can be adjusted in height.

Easy to operate

Drying temperature and drying time settings, burner operation, circulation fan operation, etc. can be centrally controlled from the control panel.
Error indications are coded and displayed on the control panel.
For the 2-burner type, the control panel can be connected to a parent and child using one communication line, and can be operated with one unit on each side. Independent operation of the parent unit and slave unit can be switched with a switch.

Stable furnace temperature

A hot air circulation method is adopted, and time proportional control is performed by a microcomputer. Furthermore, the air outlet inside the furnace is equipped with a gallery for adjusting the wind direction as standard to ensure uniform temperature within the furnace (within ±10℃).
The CUG type uses a special gun-type burner that has excellent ignitability and is easy to maintain.

shut out dust

Filters are installed at the fresh air intake and the outlet inside the furnace to prevent dust from adhering.
The inner and outer plates are molten aluminum-zinc alloy plated steel sheets. Since it is not painted, there is no dust generation.

specification
