Features
All of the electrical components of the BBL type mentioned above are designed to be explosion-proof for increased safety.
However, the primary side wiring, cover switch, etc. (dotted lines in the diagram below) are to be carried out by the customer.
specification
| format | Body dimensions Frontage (W) [mm] | Body dimensions Depth (D) [mm] | Body dimensions Ceiling height (h) [mm] | Body dimensions Total height (H) [mm] | Collection efficiency melamine paint | Collection efficiency Lacquer primer paint | Collection efficiency Acrylic urethane paint | Collection efficiency Phthalate-based acrylic paint | Noise (front of device) [dB(A)] | Average wind speed [m/s] | Exhaust fan motor output [kW] | Primary power supply phase | Primary power supply [V] | Frequency [Hz] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BBD-15H-M5 | 1500 | 1500 | 2000 | 2475 | 96 | 92 | 88 | 90 | 76 | 0.65 | 0.75 | -- | -- | -- |
| BBD-20H-M5 | 2000 | 1500 | 2000 | 2475 | 96 | 92 | 88 | 90 | 82 | 0.65 | 1.5 | -- | -- | -- |
| BBD-25H-M5 | 2500 | 1500 | 2000 | 2475 | 96 | 92 | 88 | 90 | 82 | 0.65 | 1.5 | -- | -- | -- |
| BBD-30H-M5 | 3000 | 1500 | 2000 | 2545 | 96 | 92 | 88 | 90 | 79 | 0.65 | 2.2 | -- | -- | -- |
| BBD-35H-M5 | 3500 | 1500 | 2000 | 2545 | 96 | 92 | 88 | 90 | 79 | 0.65 | 2.2 | -- | -- | -- |
| BBD-40H-M5 | 4000 | 1500 | 2000 | 2545 | 96 | 92 | 88 | 90 | 84 | 0.65 | 3.7 | -- | -- | -- |
| BBD-45H-M5 | 4500 | 1500 | 2000 | 2545 | 96 | 92 | 88 | 90 | 84 | 0.65 | 3.7 | -- | -- | -- |
| BBD-15H-M6 | 1500 | 1500 | 2000 | 2475 | 96 | 92 | 88 | 90 | 76 | 0.65 | 0.75 | -- | -- | -- |
| BBD-20H-M6 | 2000 | 1500 | 2000 | 2475 | 96 | 92 | 88 | 90 | 82 | 0.65 | 1.5 | -- | -- | -- |
| BBD-25H-M6 | 2500 | 1500 | 2000 | 2475 | 96 | 92 | 88 | 90 | 82 | 0.65 | 1.5 | -- | -- | -- |
| BBD-30H-M6 | 3000 | 1500 | 2000 | 2545 | 96 | 92 | 88 | 90 | 79 | 0.65 | 2.2 | -- | -- | -- |
| BBD-35H-M6 | 3500 | 1500 | 2000 | 2545 | 96 | 92 | 88 | 90 | 79 | 0.65 | 2.2 | -- | -- | -- |
| BBD-40H-M6 | 4000 | 1500 | 2000 | 2545 | 96 | 92 | 88 | 90 | 84 | 0.65 | 3.7 | -- | -- | -- |
| BBD-45H-M6 | 4500 | 1500 | 2000 | 2545 | 96 | 92 | 88 | 90 | 84 | 0.65 | 3.7 | -- | -- | -- |
