Features

① Inherits the high maintenance and high collection efficiency that are the features of the current VB-F model. In addition, it is equipped with an upper water flow plate, rectifier plate, and overflow tank that are removable and easy to maintain.
② Stainless steel plate is used as the material of the water flow plate, giving consideration to aesthetics and durability.The
submersible pump is unaffected by the water level due to its "low water level cooling mechanism." This also eliminates the hassle of water leaking from the gland packing.
By using a coarse resin filter, the structure is easy to maintain and highly economical. A loop water flow system is used to supply water to the water flow plate. We have reduced sludge accumulation in the overflow tank and achieved long-term stabilization of the water film.


Other accessories

・Sludge Killer (SK-510/520, 1 box each)
・Swing rack (pour stand for sludge killer)
・2 measuring cups
・1 roll of pH test paper
・Sandpaper (P400)


specification

formatBody dimensions Frontage (W) [mm]Body dimensions Depth (D) [mm]Body dimensions Ceiling height (h) [mm]Body dimensions Total height (H) [mm]Collection efficiency melamine paintCollection efficiency Lacquer primer paintCollection efficiency Acrylic urethane paintCollection efficiency Phthalate-based acrylic paintNoise (front of device) [dB(A)]Average wind speed [m/s]Exhaust fan motor output [kW]Submersible pump output [kW]Primary power supply phasePrimary power supply [V]Frequency [Hz]
VBW-15F-M5 1500 2000 2000 2912 99 99 97 98 81 0.6 0.4 0.4 Three-phase 200 50
VBW-20F-M5 2000 2000 2000 2965 99 99 97 98 81 0.6 0.4 0.4 Three-phase 200 50
VBW-25F-M5 2500 2000 2000 3008 99 99 97 98 81 0.6 0.75 0.75 Three-phase 200 50
VBW-30F-M5 3000 2000 2000 3008 99 99 97 98 81 0.6 0.75 0.75 Three-phase 200 50
VBW-15F-M6 1500 2000 2000 2912 99 99 97 98 81 0.6 0.4 0.4 Three-phase 200 60
VBW-20F-M6 2000 2000 2000 2965 99 99 97 98 81 0.6 0.4 0.4 Three-phase 200 60
VBW-25F-M6 2500 2000 2000 2952 99 99 97 98 81 0.6 0.75 0.75 Three-phase 200 60
VBW-30F-M6 3000 2000 2000 3008 99 99 97 98 81 0.6 0.75 0.75 Three-phase 200 60
