Standard model of claw compressor. In addition to unloading control (no-load operation) during operation, the system automatically starts and stops up to 10 times per hour, reducing unnecessary unloading operations and increasing energy savings.

Purpose

Features

The claw body has become a double tooth, with two compressions per rotation, further increasing efficiency and increasing air volume by up to 5% compared to conventional models. (Compared to our company)
The uniquely shaped claw (tooth) type compressor is composed of two rotors, male and female, which rotate without contacting each other and have a long life with no wear.
The precision-designed rotor is made of stainless steel and is resistant to corrosion, and the rotor is symmetrical about the axis so there is no wobbling.
The inside of the casing and the surface of the female rotor are treated with a special coating, making them even more airtight.
The suction and discharge ports are located in symmetrical planes with respect to the rotor, which eliminates axial load and extends the life of the bearing.
The double tooth body is a completely air-cooled type that does not require cooling liquid (oil, water, coolant). Maintenance is easy as no extra auxiliary equipment is required.
We have semi-standardized the use of 0.85MPa and will respond to your requests. The SPM® Shock Pulse Bearing Diagnostic System allows you to diagnose the main body bearing and pre-check the bearing life
by connecting a measuring device to the measuring plug attached to the compressor element (main body), allowing preventive maintenance and optimal maintenance.
operation can be realized.

Specification
